These internal halyard flagpoles contain a winch mounted inside the flagpole shaft,
operable only with a removable crank handle. As the stainless steel cable unwinds
from the winch, it passes up through the inside of the flagpole shaft, over the truck
sheave to the outside of the shaft, where the retainer ring provides a sliding anchor.
A counterweight, heavily coated with neoprene, attached to the retainer ring, allows
the halyard to be lowered for fastening or removing the flag. The winch is gearless
and self-locking at any point, eliminating the need for a separate brake. This direct
drive winch provides rapid raising and lowering of the flag with little effort. This design
does not require any welding, thus avoiding discoloration when an anodized finish is
desired. No monthly lubrication is needed.

STANDARD ACCESSORIES
• Gold anodized aluminum ball ornament
• Cast aluminum revolving truck w/pulley
• Solid braided polyester halyard
• Swivel flag snaps w/vinyl snap covers

• Cast aluminum cleat with mounting screws
• Spun aluminum flash collar
• Galvanized steel foundation sleeve
